Production Data
WM8912
REGISTER
ADDRESS
BIT
LABEL
DEFAULT
DESCRIPTION
REFER TO
R157 (9Dh)
EQ24
15:0
EQ_B5_PG
[15:0]
0100_0000 EQ Band 5 Coefficient PG
_0000_000
0
Register 9Dh EQ24
REGISTER
ADDRESS
BIT
LABEL
DEFAULT
DESCRIPTION
REFER TO
R247 (F7h)
FLL NCO
Test 0
0
FLL_FRC_NC
O
0
FLL Forced control select
0 = Normal
1 = FLL oscillator controlled by FLL_FRC_NCO_VAL
(Note that this field is required for free-running FLL
modes only)
Register F7h FLL NCO Test 0
REGISTER
ADDRESS
BIT
LABEL
DEFAULT
DESCRIPTION
REFER TO
R248 (F8h)
FLL NCO
Test 1
5:0
FLL_FRC_NC
O_VAL [5:0]
01_1001 FLL Forced oscillator value
Valid range is 000000 to 111111
0x19h (011001) = 12MHz approx
(Note that this field is required for free-running FLL
modes only)
Register F8h FLL NCO Test 1
PD, Rev 4.0, September 2010
125
