Production Data
WM8352
REGISTER
ADDRESS
BIT
LABEL
DEFAULT
DESCRIPTION
DCOMP2 source select.
REFER TO
R165 (A5h) 15:13 DCMP2_SRCSEL[2:0]
000
Generic
comparator
2
000 = AUX1
001 = AUX2
010 = AUX3
011 = AUX4
100 = USB
101 = LINE
110 = BATT
111 = TEMP
Reset by state machine.
DCOMP2 interrupt control
12
DCMP2_GT
0
0 = interrupt when the source is less than
threshold
1 = interrupt when the source is greater
than threshold
11:0
DCMP2_THR[11:0]
0000_0000_0000 DCOMP2 threshold
(12-bit unsigned binary number)
Register A5h Generic comparator 2
REGISTER
ADDRESS
BIT
LABEL
DEFAULT
DESCRIPTION
DCOMP3 source select.
REFER TO
R166 (A6h) 15:13 DCMP3_SRCSEL[2:0]
000
Generic
comparator
3
000 = AUX1
001 = AUX2
010 = AUX3
011 = AUX4
100 = USB
101 = LINE
110 = BATT
111 = TEMP
Reset by state machine.
DCOMP3 interrupt control
12
DCMP3_GT
0
0 = interrupt when the source is less than
threshold
1 = interrupt when the source is greater
than threshold
11:0
DCMP3_THR[11:0]
0000_0000_0000 DCOMP3 threshold
(12-bit unsigned binary number)
Register A6h Generic comparator 3
PD, February 2011, Rev 4.4
281
