W83697HF/F
10.4 Chip (Global) Control Register
CR02 (Default 0x00)
Bit 7 - 1 : Reserved.
Bit 0
: SWRST --> Soft Reset.
CR07
Bit 7 - 0 : LDNB7 - LDNB0 --> Logical Device Number Bit 7 - 0
CR20
Bit 7 - 0 : DEVIDB7 - DEBIDB0 --> Device ID Bit 7 - Bit 0 = 0x 60 (read only).
CR21
Bit 7 - 0 : DEVREVB7 - DEBREVB0 --> Device Rev = 0x1X (read only).
X
: Version change number .(Bit 3~0).
CR22 (Default 0xff)
Bit 7~ 5 : Reserved.
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
: HMPWD
= 0 Power down
= 1 No Power down
: URBPWD
= 0 Power down
= 1 No Power down
: URAPWD
= 0 Power down
= 1 No Power down
: PRTPWD
= 0 Power down
= 1 No Power down
: FDCPWD
= 0 Power down
= 1 No Power down
Publication Release Date: Feb. 2002
Revision 0.70
- 136 -
