W25Q16DV
7.2.4 Instruction Set Table 3 (ID, Security Instructions)
INSTRUCTION
NAME
BYTE 1
(CODE)
BYTE 2
BYTE 3
BYTE 4
BYTE 5
BYTE 6
Release Power down /
Device ID
(1)
ABh
dummy
dummy
dummy
(ID7-ID0)
Manufacturer/
90h
92h
94h
dummy
A23-A8
dummy
00h
(MF7-MF0)
(ID7-ID0)
(2)
Device ID
Manufacturer/Device ID
by Dual I/O
A7-A0, M[7:0]
(MF[7:0], ID[7:0])
Manufacture/Device ID
by Quad I/O
A23-A0, M[7:0] xxxx, (MF[7:0], ID[7:0]) (MF[7:0], ID[7:0], …)
(MF7-MF0)
(ID15-ID8)
(ID7-ID0)
Capacity
JEDEC ID
9Fh
Manufacturer
Memory Type
Read Unique ID
4Bh
5Ah
dummy
00h
dummy
00h
dummy
A7–A0
dummy
dummy
(ID63-ID0)
(D7-0)
Read SFDP Register
Erase
44h
42h
48h
A23–A16
A23–A16
A23–A16
A15–A8
A15–A8
A15–A8
A7–A0
A7–A0
A7–A0
Security Registers(3)
Program
Security Registers(3)
(D7-0)
(D7-0)
(D7-0)
Read
Security Registers(3)
dummy
Enable Reset
Reset
66h
99h
Notes:
1. The Device ID will repeat continuously until /CS terminates the instruction.
2. See Manufacturer and Device Identification table for Device ID information.
3. Security Register Address:
Security Register 1: A23-16 = 00h; A15-8 = 10h; A7-0 = byte address
Security Register 2: A23-16 = 00h; A15-8 = 20h; A7-0 = byte address
Security Register 3: A23-16 = 00h; A15-8 = 30h; A7-0 = byte address
- 22 -
