195D
Solid Tantalum Chip Capacitors
TANTAMOUNT® Conformal Coated
Vishay Sprague
STANDARD RATINGS
Max. DCL
at + 25 °C
(µA)
Max. DF
at + 25 °C
120 Hz (%)
CAPACITANCE (µF)
CASE CODE
PART NUMBER
10 WVDC AT + 85 °C, SURGE = 13 V . . . 7 WVDC AT + 125 °C, SURGE = 9 V
1.0
2.2
4.7
6.8
15
A
B
D
E
F
195D105X_010A2T
195D225X_010B2T
195D475X_010D2T
195D685X_010E2T
195D156X_010F2T
195D476X_010H2E
0.5
0.5
0.5
0.7
1.5
4.7
6
6
6
6
6
6
47
H
15 / 16 WVDC AT + 85 °C, SURGE = 20 V...10 WVDC AT + 125 °C, SURGE = 12 V
0.47
0.68
1.0
1.5
3.3
4.7
10
A
A
B
B
D
E
F
195D474X_015A2T
195D684X_015A2T
195D105X_015B2T
195D155X_015B2T
195D335X_015D2T
195D475X_015E2T
195D106X_015F2T
195D226X_015G2T
195D336X_015H2E
0.5
0.5
0.5
0.5
0.5
0.7
1.5
3.3
5.0
6
6
6
6
6
6
6
6
6
22
G
H
33
20 WVDC AT + 85 °C, SURGE = 26 V . . . 13 WVDC AT + 125 °C, SURGE = 16 V
0.47
1.0
2.2
3.3
6.8
15
A
B
D
E
F
195D474X_020A2T
195D105X_020B2T
195D225X_020D2T
195D335X_020E2T
195D685X_020F2T
195D156X_020G2T
195D226X_020H2E
0.5
0.5
0.5
0.7
1.4
3.0
4.4
6
6
6
6
6
6
6
G
H
22
25 WVDC AT + 85 °C, SURGE = 32 V . . . 17 WVDC AT + 125 °C, SURGE = 20 V
0.33
0.68
1.5
2.2
4.7
6.8
10
A
B
D
E
F
195D334X_025A2T
195D684X_025B2T
195D155X_025D2T
195D225X_025E2T
195D475X_025F2T
195D685X_025G2T
195D106X_025G2T
195D156X_025H2E
0.5
0.5
0.5
0.6
1.2
1.7
2.5
3.8
6
6
6
6
6
6
6
6
G
G
H
15
For 10 % tolerance, specify “9“: for 20 % tolerance, change to “0“.
www.vishay.com
9
For technical questions, contact: tantalum@vishay.com
Document Number: 40001
Revision: 16-May-06
VISHAY [ VISHAY ]
