195D
Vishay Sprague
Solid Tantalum Chip Capacitors
TANTAMOUNT® Conformal Coated
STANDARD RATINGS
Max. DCL
at + 25 °C
(µA)
Max. DF
at + 25 °C
120 Hz (%)
CAPACITANCE (µF)
CASE CODE
PART NUMBER*
20 WVDC AT + 85 °C, SURGE = 26 V . . . 13 WVDC AT + 125 °C, SURGE = 16 V
0.68
1.0
1.5
2.2
3.3
4.7
6.8
10
C
S
S
S
V
X
X
Y
Z
Z
R
R
195D684X_020C2T
195D105X_020S2T
195D155X_020S2T
195D225X_020S2T
195D335X_020V2T
195D475X_020X2T
195D685X_020X2T
195D106X_020Y2T
195D156X_020Z2T
195D226X_020Z2T
195D336X_020R2T
195D476X_020R2T
0.5
0.5
0.5
0.5
0.7
0.9
1.4
2.0
3.0
4.4
6.6
9.4
4
4
6
6
6
6
6
6
6
6
6
6
15
22
33
47
25 WVDC AT + 85 °C, SURGE = 32 V . . . 17 WVDC AT + 125 °C, SURGE = 20 V
0.47
0.68
1.0
1.5
2.2
3.3
4.7
6.8
10
C
S
S
S
V
X
X
Y
Y
Z
195D474X_025C2T
195D684X_025S2T
195D105X_025S2T
195D155X_025S2T
195D225X_025V2T
195D335X_025X2T
195D475X_025X2T
195D685X_025Y2T
195D106X_025Y2T
195D156X_025Z2T
195D226X_025R2T
195D336X_025R2T
0.5
0.5
0.5
0.5
0.6
0.8
1.2
1.7
2.5
3.8
5.5
8.3
4
4
4
6
6
6
6
6
6
6
6
6
15
22
R
R
33
35 WVDC AT + 85 °C, SURGE = 46 V . . . 23 WVDC AT + 125 °C, SURGE = 28 V
0.33
0.47
0.68
1.0
1.5
2.2
3.3
4.7
6.8
10
C
S
S
S
V
X
Y
Z
Z
Z
R
R
195D334X_035C2T
195D474X_035S2T
195D684X_035S2T
195D105X_035S2T
195D155X_035V2T
195D225X_035X2T
195D335X_035Y2T
195D475X_035Z2T
195D685X_035Z2T
195D106X_035Z2T
195D156X_035R2T
195D226X_035R2T
0.5
0.5
0.5
0.5
0.5
0.8
1.2
1.6
2.4
3.5
5.3
7.7
4
4
4
4
6
6
6
6
6
6
6
6
15
22
For 10 % tolerance, specify “9“: for 20 % tolerance, change to “0“.
