10-FZ06NBA050SA-P915L33
datasheet
Maximum Ratings
Tj = 25 °C, unless otherwise specified
Parameter
Symbol
Conditions
Value
Unit
Boost Switch
VCES
Collector-emitter voltage
600
51
V
A
IC
Collector current (DC current)
Repetitive peak collector current
Total power dissipation
Tj = Tjmax
Ts = 80 °C
Ts = 80 °C
Tj = 150 °C
ICRM
tp limited by Tjmax
Tj = Tjmax
150
90
A
Ptot
W
V
VGES
Gate-emitter voltage
±20
6
tSC
Short circuit ratings
VGE = 15 V, VCC = 360 V
µs
°C
Tjmax
Maximum junction temperature
175
Boost Diode
VRRM
Peak repetitive reverse voltage
600
46
V
A
IF
Forward current (DC current)
Repetitive peak forward current
Total power dissipation
Tj = Tjmax
Ts = 80 °C
Ts = 80 °C
IFRM
tp limited by Tjmax
Tj = Tjmax
100
68
A
Ptot
W
°C
Tjmax
Maximum junction temperature
175
Boost Sw. Protection Diode
VRRM
Peak repetitive reverse voltage
Forward current (DC current)
Repetitive peak forward current
Total power dissipation
600
27
V
A
IF
Tj = Tjmax
Ts = 80 °C
Ts = 80 °C
IFRM
tp limited by Tjmax
Tj = Tjmax
40
A
Ptot
44
W
°C
Tjmax
Maximum junction temperature
175
