Address
Registername
Name
Access
Mask
Type
Bool
Unit
0x00000004h
GPIO_dsADCI_CONFIG[2]
Min
0
Max
1
Default
0
SEL_nGPIO_dsADCS_B
0: off
1: on
Mask
Name
GPIO_dsADCI_CONFIG[3]
Type
Bool
Unit
0x00000008h
Min
0
Max
1
Default
0
SEL_GPIO_GROUP_A_nIN_OUT
0: off
1: on
Name
Mask
Type
Bool
Unit
0x00000010h
GPIO_dsADCI_CONFIG[4]
Min
0
Max
1
Default
0
SEL_GPIO_GROUP_B_nIN_OUT
0: off
1: on
Name
Mask
Type
Bool
Unit
0x00000020h
GPIO_dsADCI_CONFIG[5]
Min
0
Max
1
Default
0
SEL_GROUP_A_DSADCS_nCLKIN_CLKOUT
0: off
1: on
Mask
Name
Type
Bool
Unit
0x00000040h
GPIO_dsADCI_CONFIG[6]
Min
0
Max
1
Default
0
SEL_GROUP_B_DSADCS_nCLKIN_CLKOUT
0: off
1: on
