TLP291-4
3.6 Reel
(1) Material: Plastic
(2) Dimensions: The reel dimensions are as shown in Figure 3 and Table 3.
Table 3 Reel Dimensions
Unit: mm
Symbol
Dimension
A
B
ꢃ330 ꢂ 2
ꢃ80 ꢂ 1
U
E
C
ꢃ13 ꢂ 0.5
2.0 ꢂ 0.5
4.0 ꢂ 0.5
17.5 ꢂ 0.5
21.5 ꢂ 1.0
E
U
W1
W2
W1
W2
Figure 3 Reel Forms
4. Packing
Either one reel or five reels of photocouplers are packed in a shipping carton.
5. Label Indication
The carton bears a label indicating the product number, the symbol representing classification of
standard, the quantity, the lot number and the Toshiba company name.
6. Ordering Method
When placing an order, please specify the product number, the CTR rank, the tape type and the quantity
as shown in the following example.
（Example）
TLP291-4(GB-TP,E 2000 Pcs
Quantity (must be a multiple of 2000)
[[G]]/RoHS COMPATIBLE (Note6)
Tape type
CTR rank
Device name
Note6:Please contact your TOSHIBA sales representative for details as to environmental matters such as the
RoHS compatibility of Product.
The RoHS is the Directive 2002/95/EC of the European Parliament and of the Council of 27 January 2003
on the restriction of the use of certain hazardous substances in electrical and electronics equipment.
9
2011-09-08
