PACKAGE OUTLINE
DW0016B
SOIC - 2.65 mm max height
S
C
A
L
E
1
.
5
0
0
SOIC
C
10.63
9.97
SEATING PLANE
TYP
PIN 1 ID
AREA
0.1 C
A
14X 1.27
16
1
2X
10.5
10.1
NOTE 3
8.89
8
9
0.51
0.31
16X
7.6
7.4
B
2.65 MAX
0.25
C A
B
NOTE 4
0.33
0.10
TYP
SEE DETAIL A
0.25
GAGE PLANE
0.3
0.1
0 - 8
1.27
0.40
DETAIL A
TYPICAL
(1.4)
4221009/B 07/2016
NOTES:
1. All linear dimensions are in millimeters. Dimensions in parenthesis are for reference only. Dimensioning and tolerancing
per ASME Y14.5M.
2. This drawing is subject to change without notice.
3. This dimension does not include mold flash, protrusions, or gate burrs. Mold flash, protrusions, or gate burrs shall not
exceed 0.15 mm, per side.
4. This dimension does not include interlead flash. Interlead flash shall not exceed 0.25 mm, per side.
5. Reference JEDEC registration MS-013.
