VDD1 SMPS (continued)
over operating free-air temperature range (unless otherwise noted)
PARAMETER
TEST CONDITIONS
MIN
TYP
MAX
UNIT
%
Duty cycle
100
Minimum on time tON(MIN)
P-channel MOSFET
35
ns
VFB1 internal resistance
0.5
1
MΩ
Discharge resistor for power-down
sequence RDIS
30
50
1
Ω
Ground current (IQ)
Off
PWM mode, IOUT = 0 mA, VIN = 3.8 V,
VDD1_PSKIP = 0
7500
78
µA
Pulse skipping mode, no switching
Low-power (pulse skipping) mode, no switching
ST[1:0] = 11
63
PWM mode, DCRL < 0.1 Ω, VOUT = 1.2 V, VIN
3.6 V:
=
Conversion efficiency
IOUT = 10 mA
IOUT = 200 mA
IOUT = 400 mA
IOUT = 800 mA
IOUT = 1500 mA
35%
82%
81%
74%
62%
Pulse skipping mode, DCRL < 0.1Ω, VOUT = 1.2
V, VIN = 3.6 V:
IOUT = 1 mA
59%
70%
82%
IOUT = 10 mA
IOUT = 200 mA
