PACKAGE OUTLINE
DRL0008A
SOT-5X3 - 0.6 mm max height
S
C
A
L
E
8
.
0
0
0
PLASTIC SMALL OUTLINE
1.3
1.1
B
A
PIN 1
ID AREA
1
8
6X 0.5
2.2
2.0
2X 1.5
NOTE 3
5
4
0.27
0.17
8X
1.7
1.5
0.05
0.00
0.1
C A B
0.05
C
0.6 MAX
SEATING PLANE
0.05 C
0.18
0.08
SYMM
0.4
0.2
8X
SYMM
4224486/E 12/2021
NOTES:
1. All linear dimensions are in millimeters. Any dimensions in parenthesis are for reference only. Dimensioning and tolerancing
per ASME Y14.5M.
2. This drawing is subject to change without notice.
3. This dimension does not include mold flash, protrusions, or gate burrs. Mold flash, interlead flash, protrusions, or gate burrs shall not
exceed 0.15 mm per side.
4.Reference JEDEC Registration MO-293, Variation UDAD
