TMS570LS3137
www.ti.com
SPNS162.–SEPTEMBER 2011
2.4.1.16 Supply for Core Logic: 1.2V nominal
Table 2-20. PGE Supply for Core Logic: 1.2V nominal
Terminal
Signal
Type
Default
Pull State
Pull Type
Description
Signal Name
144
PGE
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
VCC
17
29
-
-
-
Core supply
45
48
49
57
87
101
114
123
137
143
2.4.1.17 Supply for I/O Cells: 3.3V nominal
Table 2-21. PGE Supply for I/O Cells: 3.3V nominal
Terminal
Signal
Type
Default
Pull State
Pull Type
Description
Signal Name
144
PGE
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
10
26
Input
-
-
Operating supply for I/Os
42
104
120
136
Copyright © 2011, Texas Instruments Incorporated
Device Package and Terminal Functions
21
