DMA
XINT3
Interrupt Control
XINT3CR(15:0)
Latch
GPIOXINT3SEL(4:0)
DMA
XINT4
Interrupt Control
XINT4CR(15:0)
Latch
GPIOXINT4SEL(4:0)
DMA
XINT5
INT1
to
INT12
PIE
Latch
Interrupt Control
XINT5CR(15:0)
C28
Core
GPIOXINT5SEL(4:0)
DMA
XINT6
Interrupt Control
XINT6CR(15:0)
Latch
GPIOXINT6SEL(4:0)
DMA
XINT7
GPIO32.int
GPIO63.int
GPIO
Mux
Interrupt Control
XINT7CR(15:0)
Latch
GPIOXINT7SEL(4:0)
Figure 3-6. External Interrupts
Eight PIE block interrupts are grouped into one CPU interrupt. In total, 12 CPU interrupt groups, with
8 interrupts per group equals 96 possible interrupts. On the 2833x/2823x devices, 58 of these are used by
peripherals as shown in Table 3-13.
The TRAP #VectorNumber instruction transfers program control to the interrupt service routine
corresponding to the vector specified. TRAP #0 attempts to transfer program control to the address
pointed to by the reset vector. The PIE vector table does not, however, include a reset vector. Therefore,
TRAP #0 should not be used when the PIE is enabled. Doing so will result in undefined behavior.
When the PIE is enabled, TRAP #1 through TRAP #12 will transfer program control to the interrupt service
routine corresponding to the first vector within the PIE group. For example: TRAP #1 fetches the vector
from INT1.1, TRAP #2 fetches the vector from INT2.1, and so forth.
