表9-27. ePWM Control and Status Registers (continued)
SIZE (x16) /
#SHADOW
NAME
ePWM1
ePWM2
ePWM3
ePWM4
DESCRIPTION
DCCAPCT
0x6834
0x6835
0x6874
0x6875
0x68B4
0x68B5
0x68F4
0x68F5
1 / 0
Digital Compare Capture Control Register(1)
Digital Compare Filter Offset Register
DCFOFFSET
1 / 1
DCFOFFSETCN
T
0x6836
0x6837
0x6838
0x6839
0x6876
0x6877
0x6878
0x6879
0x68B6
0x68B7
0x68B8
0x68B9
0x68F6
0x68F7
0x68F8
0x68F9
1 / 0
1 / 0
1 / 0
1 / 1
Digital Compare Filter Offset Counter Register
Digital Compare Filter Window Register
DCFWINDOW
DCFWINDOWCN
T
Digital Compare Filter Window Counter
Register
DCCAP
Digital Compare Counter Capture Register
(1) Registers that are EALLOW protected.
(2) W = Write to shadow register
