TMS320C6672
Multicore Fixed and Floating-Point Digital Signal Processor
SPRS708C—February 2012
www.ti.com
Table 2-19
Terminal Functions
— By Ball Number
(Part 21 of 21)
Ball Number
AJ14
Signal Name
RIORXP3
RIORXN3
VSS
AJ15
AJ16
AJ17
SGMII0RXP
SGMII0RXN
VSS
AJ18
AJ19
AJ20
TR15
AJ21
TR13
AJ22
FSB1
AJ23
CLKA1
TX02
AJ24
AJ25
TR01
AJ26
FSA0
AJ27
EMU16
DVDD18
VSS
AJ28
AJ29
End of Table 2-19
2.9 Development and Support
2.9.1 Development Support
In case the customer would like to develop their own features and software on the C6672 device, TI offers an
extensive line of development tools for the TMS320C6000™ DSP platform, including tools to evaluate the
performance of the processors, generate code, develop algorithm implementations, and fully integrate and debug
software and hardware modules. The tool's support documentation is electronically available within the Code
Composer Studio™ Integrated Development Environment (IDE).
The following products support development of C6000™ DSP-based applications:
•
Software Development Tools:
–
Code Composer Studio™ Integrated Development Environment (IDE), including Editor C/C++/Assembly
Code Generation, and Debug plus additional development tools.
–
Scalable, Real-Time Foundation Software (DSP/BIOS™), which provides the basic run-time target software
needed to support any DSP application.
•
Hardware Development Tools:
–
–
Extended Development System (XDS™) Emulator (supports C6000™ DSP multiprocessor system debug)
EVM (Evaluation Module)
66
Device Overview
Copyright 2012 Texas Instruments Incorporated
TI [ TEXAS INSTRUMENTS ]
