TMS320F2809, TMS320F2808, TMS320F2806
TMS320F2802, TMS320F2801, UCD9501
TMS320C2802, TMS320C2801, and TMS320F2801x DSPs
www.ti.com
SPRS230H–OCTOBER 2003–REVISED JUNE 2006
1
F280x, F2801x, C280x, UCD9501 DSPs
1.1 Features
–
Up to 6 HRPWM Outputs With 150 ps MEP
Resolution
Up to Four Capture Inputs
Up to Two Quadrature Encoder Interfaces
Up to Six 32-bit/Six 16-bit Timers
•
High-Performance Static CMOS Technology
–
–
–
100 MHz (10-ns Cycle Time)
60 MHz (16.67-ns Cycle Time)
Low-Power (1.8-V Core, 3.3-V I/O) Design
–
–
–
•
•
JTAG Boundary Scan Support(1)
•
•
Serial Port Peripherals
High-Performance 32-Bit CPU (TMS320C28x)
–
–
–
–
Up to 4 SPI Modules
–
–
–
–
–
–
–
16 x 16 and 32 x 32 MAC Operations
16 x 16 Dual MAC
Harvard Bus Architecture
Up to 2 SCI (UART) Modules
Up to 2 CAN Modules
One Inter-Integrated-Circuit (I2C) Bus
Atomic Operations
12-Bit ADC, 16 Channels
Fast Interrupt Response and Processing
Unified Memory Programming Model
Code-Efficient (in C/C++ and Assembly)
–
–
–
–
2 x 8 Channel Input Multiplexer
Two Sample-and-Hold
Single/Simultaneous Conversions
•
On-Chip Memory
Fast Conversion Rate:
–
F2809: 128K X 16 Flash, 18K X 16 SARAM
F2808: 64K X 16 Flash, 18K X 16 SARAM
F2806: 32K X 16 Flash, 10K X 16 SARAM
F2802: 32K X 16 Flash, 6K X 16 SARAM
F2801: 16K X 16 Flash, 6K X 16 SARAM
9501: 16K X 16 Flash, 6K X 16 SARAM
F2801x: 16K X 16 Flash, 6K X 16 SARAM
80 ns - 12.5 MSPS (F2809 only)
160 ns - 6.25 MSPS (280x, 9501)
267 ns - 3.75 MSPS (F2801x)
–
Internal or External Reference
•
•
Up to 35 Individually Programmable,
Multiplexed GPIO Pins With Input Filtering
–
–
1K x 16 OTP ROM (Flash Devices Only)
C2802: 32K X 16 ROM, 6K X 16 SARAM
C2801: 16K X 16 ROM, 6K X 16 SARAM
Advanced Emulation Features
–
–
Analysis and Breakpoint Functions
Real-Time Debug via Hardware
•
•
Boot ROM (4K x 16)
•
Development Support Includes
–
With Software Boot Modes (via SCI, SPI,
–
–
–
–
ANSI C/C++ Compiler/Assembler/Linker
Code Composer Studio™ IDE
DSP/BIOS™
Digital Motor Control and Digital Power
Software Libraries
CAN, I2C, and Parallel I/O)
–
Standard Math Tables
Clock and System Control
–
–
–
Dynamic PLL Ratio Changes Supported
On-Chip Oscillator
Watchdog Timer Module
•
•
•
Low-Power Modes and Power Savings
–
–
IDLE, STANDBY, HALT Modes Supported
Disable Individual Peripheral Clocks
•
•
•
Any GPIO A Pin Can Be Connected to One of
the Three External Core Interrupts
Package Options
Peripheral Interrupt Expansion (PIE) Block
That Supports All 43 Peripheral Interrupts
–
–
Thin Quad Flatpack (PZ)
MicroStar BGA™ (GGM, ZGM)
128-Bit Security Key/Lock
Temperature Options:
–
–
Protects Flash/OTP/L0/L1 Blocks
Prevents Firmware Reverse Engineering
–
–
–
A: -40°C to 85°C (PZ, GGM, ZGM)
S: -40°C to 125°C (PZ, GGM, ZGM)
Q: -40°C to 125°C (PZ)
•
•
Three 32-Bit CPU Timers
Enhanced Control Peripherals
–
Up to 16 PWM Outputs
(1) IEEE Standard 1149.1-1990 Standard Test Access Port and
Boundary Scan Architecture
