RM46L450
RM46L850
www.ti.com
SPNS184 –SEPTEMBER 2012
Table 2-17. PGE USB Device Port Controller Interface (USB_FUNC)
Terminal
Signal
Type
Default
Pull State
Pull Type
Description
Signal Name
144
PGE
N2HET1[07]/USB2.PortPower/USB_FUNC.GZO/N2HET2[14]
33
Output Pull Down
-
Pull Up enable, allows for
software-programmable
USB device
connect/disconnect
N2HET1[01]/SPI4NENA/USB2.TXEN/USB_FUNC.PUENO/
N2HET2[8]
23
24
PUENO inverted
N2HET1[03]/SPI4NCS[0]/USB2.SPEED/USB_FUNC.PUENO
N/
N2HET2[10]/EQEP2B
GIOB[3]/USB2.RCV/USB_FUNC.RXDI
GIOA[1]/USB2.VM/USB_FUNC.RXDMI
GIOA[0]/USB2.VP/USB_FUNC.RXDPI
N2HET1[22]/USB2.TXSE0/USB_FUNC.SE0O
1
5
Input Pull Down Fixed, 20uA
USB device single-ended
data input
USB device logic value of
D-minus
2
USB device logic value of
D-plus
15
35
Output Pull Down
-
USB device single-ended
zero
N2HET1[09]/N2HET2[16]/USB2.SUSPEND/
USB_FUNC.SUSPENDO
USB device suspend
output
GIOA[2]/USB2.TXDAT/USB_FUNC.TXDO/N2HET2[0]
9
6
USB device transmit data
N2HET1[11]/MIBSPI3NCS[4]/N2HET2[18]/
USB2.OverCurrent/USB_FUNC.VBUSI/EPWM1SYNCO
Input Pull Down Fixed, 20uA
USB device power
connected
2.3.1.15 System Module Interface
Table 2-18. PGE System Module Interface
Terminal
Signal
Type
Default
Pull State
Pull Type
Description
Signal Name
144
PGE
nPORRST
46
Input
Pull Down 100uA
Power-on reset, cold reset
External power supply
monitor circuitry must
drive nPORRST low when
any of the supplies to the
microcontroller fall out of
thespecified range. This
terminal has a glitch filter.
See Section 4.8.
nRST
116
I/O
Pull Up
100uA
System reset, warm reset,
bidirectional.
The internal circuitry
indicates any reset
condition by driving nRST
low.
The external circuitry can
assert a system reset by
driving nRST low. To
ensure that an external
reset is not arbitrarily
generated, TI
recommends that an
external pull-up resistor is
connected to this terminal.
This terminal has a glitch
filter. See Section 4.8.
Copyright © 2012, Texas Instruments Incorporated
Device Package and Terminal Functions
21
