31
Update
compare
0
RTIUDCPy
+
31
0
DMAREQy
INTy
Compare
RTICOMPy
From counter
block 0
=
From counter
block 1
Compare
control
Figure 4-19. Compare Block Diagram
4.17.3 Clock Source Options
The RTI module uses the RTI1CLK clock domain for generating the RTI time bases.
The application can select the clock source for the RTI1CLK by configuring the RCLKSRC register in the
System module at address 0xFFFFFF50. The default source for RTI1CLK is VCLK.
For more information on clock sources refer to Table 4-8 and Table 4-13.
4.17.4 Network Time Synchronization Inputs
The RTI module supports 4 Network Time Unit (NTU) inputs that signal internal system events, and which
can be used to synchronize the time base used by the RTI module. On this device, these NTU inputs are
connected as shown below.
Table 4-34. Network Time Synchronization Inputs
NTU Input
Source
Reserved
0
1
2
3
Reserved
PLL2 Clock output
EXTCLKIN1 clock input
