Fully compliant with PCI-to-PCI Bridge Architecture Specification
Packaged in 160-pin QFP (PCM) and 176-pin thin QFP (PGF)
1.3 Related Documents
•
•
•
•
•
•
Advanced Configuration and Power Interface (ACPI) Revision 1.0
PCI Local Bus Specification Revision 2.2
PCI Mobile Design Guide, Revision 1.0
PCI-to-PCI Bridge Architecture Specification Revision 1.1
PCI Power Management Interface Specification Revision 1.1
PICMG Compact-PCI Hot Swap Specification Revision 1.0
1.4 Ordering Information
ORDERING NUMBER
NAME
PCI–PCI Bridge
VOLTAGE
PACKAGE
160-pin QFP
176-pin LQFP
PCI2250
3.3 V, 5-V tolerant I/Os
1–2
