ELECTRICAL CHARACTERISTICS: VS = +2.7V to +5.5V Single-Supply (Cont.)
Boldface limits apply over the specified temperature range, TA = –40°C to +125°C.
At TA = +25°C, RF = 604Ω, RL = 150Ω, and connected to VS/2, unless otherwise noted.
OPA355
OPA2355
OPA3355
PARAMETER
CONDITION
MIN
TYP
MAX
UNITS
SHUTDOWN
Disabled (Logic-LOW Threshold)(2)
Enabled (Logic-HIGH Threshold)(2)
Enable Time
0.8
V
V
2
100
30
ns
ns
µA
Disable Time
Shutdown Current (per amplifier)
VS = +5V, Disabled
3.4
6
THERMAL SHUTDOWN
Junction Temperature
Shutdown
160
140
°C
°C
Reset from Shutdown
TEMPERATURE RANGE
Specified Range
Operating Range
Storage Range
–40
–55
–65
125
150
150
°C
°C
°C
Thermal Resistance
SOT-23-6, MSOP-10
SO-8
θJA
°C/W
°C/W
°C/W
°C/W
150
125
100
SO-14, TSSOP-14
NOTES: (1) See typical characteristic Output Voltage Swing vs Output Current. (2) Logic LOW and HIGH levels are CMOS logic compatible. They are referenced to V–.
