OMAP-L137 Low-Power Applications Processor
www.ti.com
SPRS563A–SEPTEMBER 2008–REVISED OCTOBER 2008
Table 6-108. Real-Time Clock (RTC) Registers (continued)
BYTE ADDRESS
0x01C2 3024
0x01C2 3028
0x01C2 302C
0x01C2 3030
0x01C2 3034
0x01C2 3040
0x01C2 3044
0x01C2 3048
0x01C2 304C
0x01C2 3050
0x01C2 3054
0x01C2 3060
0x01C2 3064
0x01C2 3068
0x01C2 306C
0x01C2 3070
Acronym
Register Description
ALARMMINUTE
ALARMHOUR
ALARMDAY
ALARMMONTH
ALARMYEAR
CTRL
Alarm Minutes Register
Alarm Hours Register
Alarm Days Register
Alarm Months Register
Alarm Years Register
Control Register
STATUS
Status Register
INTERRUPT
COMPLSB
COMPMSB
OSC
Interrupt Enable Register
Compensation (LSB) Register
Compensation (MSB) Register
Oscillator Register
SCRATCH0
SCRATCH1
SCRATCH2
KICK0
Scratch 0 (General-Purpose) Register
Scratch 1 (General-Purpose) Register
Scratch 2 (General-Purpose) Register
Kick 0 (Write Protect) Register
Kick 1 (Write Protect) Register
KICK1
