LM359
www.ti.com
SNOSBT4C –MAY 1999–REVISED MARCH 2013
Electrical Characteristics (continued)
ISET(IN) = ISET(OUT) = 0.5 mA, Vsupply = 12V, TA = 25°C unless otherwise noted
Parameter
Conditions
Min
Typ
10.3
2
Max
Units
V
VOUT High
VOUT Low
IIN(−) and IIN(+) Grounded
IIN(−) = 100 μA, IIN(+) = 0
9.5
Output Voltage Swing (RL
= 600Ω)
50
mV
IIN(−) and IIN(+)
Grounded, RL = 100Ω
16
40
Source
V
comp−0.5V = VOUT = 1V,
4.7
Output Currents
Supply Current
Sink (Linear Region)
Sink (Overdriven)
mA
IIN(+) = 0
IIN(−) = 100 μA, IIN(+) = 0,
VOUT Force = 1V
1.5
40
3
Non-Inverting Input Grounded, RL = ∞
18.5
50
22
mA
dB
Power Supply Rejection(2) f = 120 Hz, IIN(+) Grounded
(2) See Figure 15 and Figure 16.
