EXAMPLE BOARD LAYOUT
DSG0008A
WSON - 0.8 mm max height
PLASTIC SMALL OUTLINE - NO LEAD
(0.9)
(
0.2) VIA
8X (0.5)
TYP
1
8
8X (0.25)
(0.55)
SYMM
9
(1.6)
6X (0.5)
5
4
SYMM
(1.9)
(R0.05) TYP
LAND PATTERN EXAMPLE
SCALE:20X
0.07 MIN
ALL AROUND
0.07 MAX
ALL AROUND
SOLDER MASK
OPENING
METAL
SOLDER MASK
OPENING
METAL UNDER
SOLDER MASK
NON SOLDER MASK
DEFINED
SOLDER MASK
DEFINED
(PREFERRED)
SOLDER MASK DETAILS
4218900/E 08/2022
NOTES: (continued)
4. This package is designed to be soldered to a thermal pad on the board. For more information, see Texas Instruments literature
number SLUA271 (www.ti.com/lit/slua271).
5. Vias are optional depending on application, refer to device data sheet. If any vias are implemented, refer to their locations shown
on this view. It is recommended that vias under paste be filled, plugged or tented.
