PACKAGE MATERIALS INFORMATION
www.ti.com
11-Mar-2022
TAPE AND REEL INFORMATION
*All dimensions are nominal
Device
Package Package Pins
Type Drawing
SPQ
Reel
Reel
A0
B0
K0
P1
W
Pin1
Diameter Width (mm) (mm) (mm) (mm) (mm) Quadrant
(mm) W1 (mm)
LM27761DSGR
LM27761DSGR
LM27761DSGT
LM27761DSGT
WSON
WSON
WSON
WSON
DSG
DSG
DSG
DSG
8
8
8
8
3000
3000
250
180.0
180.0
180.0
180.0
8.4
8.4
8.4
8.4
2.3
2.3
2.3
2.3
2.3
2.3
2.3
2.3
1.15
1.15
1.15
1.15
4.0
4.0
4.0
4.0
8.0
8.0
8.0
8.0
Q2
Q2
Q2
Q2
250
Pack Materials-Page 1
