CC2510Fx / CC2511Fx
P2INP (0xF7) - Port 2 Input Mode
Bit
Field Name
Reset
R/W
Description
7
PDUP2
0
R/W
Port 2 pull-up/down select. Selects function for all Port 2 pins configured as
pull-up/pull-down inputs.
0
1
Pull-up
Pull-down
6
PDUP1
0
R/W
Port 1 pull-up/down select. Selects function for all Port 1 pins configured as
pull-up/pull-down inputs, except for P1_0 and P1_1, which do not have pull-
up/down capability.
0
1
Pull-up
Pull-down
5
PDUP0
0
R/W
R/W
Port 0 pull-up/down select. Selects function for all Port 0 pins configured as
pull-up/pull-down inputs.
0
1
Pull-up
Pull-down
4:0
MDP2_[4:0]
00000
P2_4 to P2_0 I/O input mode
0
1
Pull-up / pull-down
Tristate
P0IFG (0x89) - Port 0 Interrupt Status Flag
CC2510Fx
Bit
Field Name
Reset
R/W
Description
7:0
P0IF[7:0]
0x00
R/W0
Port 0, inputs 7 to 0 interrupt status flags.
0
1
No interrupt pending
Interrupt pending
CC2511Fx
Bit
7
Field Name
Reset
R/W
Description
USB_RESUME
P0IF[5:0]
0
0
0
R/W0
R/W0
R/W0
USB resume detected during suspend mode
Not used
6
5:0
Port 0, inputs 5 to 0 interrupt status flags.
0
1
No interrupt pending
Interrupt pending
P1IFG (0x8A) - Port 1 Interrupt Status Flag
Bit
Field Name
Reset
R/W
Description
7:0
P1IF[7:0]
0x00
R/W0
Port 1, inputs 7 to 0 interrupt status flags.
0
1
No interrupt pending
Interrupt pending
P2IFG (0x8B) - Port 2 Interrupt Status Flag
Bit
7:5
4:0
Field Name
Reset
R/W
R0
Description
-
Not used
P2IF[4:0]
0
R/W0
Port 2, inputs 4 to 0 interrupt status flags.
0
1
No interrupt pending
Interrupt pending
SWRS055F
Page 96 of 241
