CC2510Fx / CC2511Fx
0xDE09: USBOIE - Out Endpoints Interrupt Enable Mask
Bit
Field Name
Reset
R/W
Description
7:6
5
00
1
R/W
R/W
Reserved. Always write 00
OUTEP5IE
OUT endpoint 5 interrupt enable
0
1
Interrupt disabled
Interrupt enabled
4
3
2
1
0
OUTEP4IE
OUTEP3IE
OUTEP2IE
OUTEP1IE
1
1
1
1
-
R/W
R/W
R/W
R/W
R0
OUT endpoint 4 interrupt enable
0
1
Interrupt disabled
Interrupt enabled
OUT endpoint 3 interrupt enable
0
1
Interrupt disabled
Interrupt enabled
OUT endpoint 2 interrupt enable
0
1
Interrupt disabled
Interrupt enabled
OUT endpoint 1 interrupt enable
0
1
Interrupt disabled
Interrupt enabled
Not used
0xDE0B: USBCIE - Common USB Interrupt Enable Mask
Bit
Field Name
Reset
R/W
Description
7:4
3
-
R0
Not used
SOFIE
0
R/W
Start-Of-Frame interrupt enable
0
1
Interrupt disabled
Interrupt enabled
2
1
0
RSTIE
1
1
0
R/W
R/W
R/W
Reset interrupt enable
0
1
Interrupt disabled
Interrupt enabled
RESUMEIE
SUSPENDIE
Resume interrupt enable
0
1
Interrupt disabled
Interrupt enabled
Suspend interrupt enable
0
1
Interrupt disabled
Interrupt enabled
0xDE0C: USBFRML - Current Frame Number (Low byte)
Bit
Field Name
Reset
R/W
Description
7:0
FRAME[7:0]
0x00
R
Low byte of 11-bit frame number
