CC1110Fx / CC1111Fx
T4CCTL0 (0xEC) - Timer 4 Channel 0 Compare Control
Bit
7
Field Name
Reset
R/W
R0
Description
-
Not used
6
IM
1
R/W
Channel 0 interrupt mask
0
1
Interrupt disabled
Interrupt enabled
5:3
CMP[2:0]
000
R/W
Channel 0 compare output mode select. Specified action on output when timer
value equals compare value in T4CC0
000
001
010
011
Set output on compare
Clear output on compare
Toggle output on compare
Set output on compare-up, clear on 0 (clear on compare-down in up/down
mode)
100
Clear output on compare-up, set on 0 (set on compare-down in up/down
mode)
101
110
111
Set output on compare, clear on 0xFF
Clear output on compare, set on 0x00
Not used
2
MODE
0
R/W
R/W
Timer 4 channel 0 compare mode enable
0
1
Disable
Enable
1:0
00
Reserved. Always write 00
T4CC0 (0xED) - Timer 4 Channel 0 Compare Value
Bit
Field Name
Reset
R/W
Description
7:0
VAL[7:0]
0x00
R/W
Timer 4 channel 0 compare value
SWRS033H
Page 138 of 246
