bq20z80-V101
www.ti.com
SLUS625D–SEPTEMBER 2004–REVISED OCTOBER 2005
Display Format - Discharge
This mode is available when SBS.BatteryStatus( ) [DSG] = 1
LED
THRESHOLD
3-LEDs
10%
4-LEDs
10%
5-LEDs
10%
USER
ALARM
DSG FLASH ALARM
DSG FLASH ALARM
1
2
3
4
5
SBS.RSOC%( )≥ DSG Thresh 1
SBS.RSOC%( )≥ DSG Thresh 2
SBS.RSOC%( )≥ DSG Thresh 3
SBS.RSOC%( )≥ DSG Thresh 4
SBS.RSOC%( )≥ DSG Thresh 5
0 to 33%
34 to 66%
67 to 100%
–
0 to 24%
25 to 49%
50 to 74%
75 to 100%
–
0 to 19%
20 to 39%
40 to 59%
60 to 79%
80 to 100%
SBS.RSOC%( ) ≥ DF:DSG Thresh 1
SBS.RSOC%( ) ≥ DF:DSG Thresh 2
SBS.RSOC%( ) ≥ DF:DSG Thresh 3
SBS.RSOC%( ) ≥ DF:DSG Thresh 4
SBS.RSOC%( ) ≥ DF:DSG Thresh 5
–
The DSG Thresh x threshold is the % of SBS.RelativeStateOfCharge( ) or SBS.AbsoluteStateOfCharge( ) to
enable the respective LED.
The DSG Flash Alarm threshold is the % of SBS.RelativeStateOfCharge( ) or SBS.AbsoluteStateOfCharge( ) at
which the remaining active LEDs flash at a 50% duty-cycle rate of DF:LED Flash Rate.
If DF:Operation Cfg A [LEDRCA] AND SBS.BatteryStatus( ) [RCA] are set, the display flashes at the DF:LED
Flash Rate with a 50% duty cycle.
If DF:Operation Cfg A [LED1, LED0] = User, the User data flash percentages are used and the values are
defined within the range indicated in the Display Timing table.
When DF:Operation Cfg A [LEDRCA] = 0, the SBS.BatteryStatus( )[RCA] is ignored.
Display Format - Charge
This mode is available when SBS.BatteryStatus( ) DSG = 0
LED
THRESHOLD
3-LEDs
10%
4-LEDs
10%
5-LEDs
10%
USER
ALARM
CHG Flash Alarm
CHG Flash Alarm
1
2
3
4
5
SBS.RSOC%( )≥ CHG Thresh 1
SBS.RSOC%( )≥ CHG Thresh 2
0 to 33%
34 to 66%
0 to 24%
25 to 49%
50 to 74%
75 to 100%
–
0 to 19%
20 to 39%
40 to 59%
60 to 79%
80 to 100%
SBS.RSOC%( )≥DF:CHG Thresh 1
SBS.RSOC%( )≥DF:CHG Thresh 2
SBS.RSOC%( )≥DF:CHG Thresh 3
SBS.RSOC%( )≥DF:CHG Thresh 4
SBS.RSOC%( )≥DF:CHG Thresh 5
SBS.RSOC%( )≥ CHG Thresh 3 67 to 100%
SBS.RSOC%( )≥ CHG Thresh 4
SBS.RSOC%( )≥ CHG Thresh 5
–
–
The CHG Thresh x threshold is the % of SBS.RelativeStateOfCharge( ) or SBS.AbsoluteStateOfCharge( ) to
enable the respective LED.
During charging the top LED segment flashs at the rate or DF:LED Blink Rate (eg: if
SBS.RelativeStateOfCharge( ) = 36% and 5 LEDs are being used then LED2 will blink).
The CHG Flash Alarm threshold is the % of SBS.RelativeStateOfCharge( ) or SBS.AbsoluteStateOfCharge( ) at
which the remaining active LEDs flash at the rate of DF:LED Flash Rate, with a 50% duty cycle.
If DF:Operation Cfg A [LEDRCA] AND SBS.BatteryStatus( ) [RCA] are set, the display flashes at the DF:LED
Flash Rate with a 50% duty cycle.
If DF:Operation Cfg A [LED1, LED0] = user, the user data flash percentages are used and the values are defined
within the range indicated in the Display Timing table.
67
