表6-27. GPMC0 Signal Descriptions (continued)
PIN TYPE
SIGNAL NAME [1]
DESCRIPTION [2]
BALL [4]
AC16
AH15
AD16
AE16
AF16
AG16
AH16
AC19
AE17
AF17
AG17
AG18
AH17
AE18
AF18
T27
[3]
GPMC address 11 Output in A/D non-multiplexed mode
and unused in A/D multiplexed mode
GPMC0_A11
GPMC0_A12
GPMC0_A13
GPMC0_A14
GPMC0_A15
GPMC0_A16
GPMC0_A17
GPMC0_A18
GPMC0_A19
GPMC0_A20
GPMC0_A21
GPMC0_A22
GPMC0_A23
GPMC0_A24
GPMC0_A25
GPMC0_A26
GPMC0_A27
OZ
OZ
OZ
OZ
OZ
OZ
OZ
OZ
OZ
OZ
OZ
OZ
OZ
OZ
OZ
OZ
OZ
GPMC address 12 Output in A/D non-multiplexed mode
and unused in A/D multiplexed mode
GPMC address 13 Output in A/D non-multiplexed mode
and unused in A/D multiplexed mode
GPMC address 14 Output in A/D non-multiplexed mode
and unused in A/D multiplexed mode
GPMC address 15 Output in A/D non-multiplexed mode
and unused in A/D multiplexed mode
GPMC address 16 Output in A/D non-multiplexed mode
and unused in A/D multiplexed mode
GPMC address 17 Output in A/D non-multiplexed mode
and unused in A/D multiplexed mode
GPMC address 18 Output in A/D non-multiplexed mode
and unused in A/D multiplexed mode
GPMC address 19 Output in A/D non-multiplexed mode
and unused in A/D multiplexed mode
GPMC address 20 Output in A/D non-multiplexed mode
and unused in A/D multiplexed mode
GPMC address 21 Output in A/D non-multiplexed mode
and unused in A/D multiplexed mode
GPMC address 22 Output in A/D non-multiplexed mode
and unused in A/D multiplexed mode
GPMC address 23 Output in A/D non-multiplexed mode
and unused in A/D multiplexed mode
GPMC address 24 Output in A/D non-multiplexed mode
and unused in A/D multiplexed mode
GPMC address 25 Output in A/D non-multiplexed mode
and unused in A/D multiplexed mode
GPMC address 26 Output in A/D non-multiplexed mode
and unused in A/D multiplexed mode
GPMC address 27 in A/D non-multiplexed mode and
Address 27 in A/D multiplexed mode
R25
GPMC Data 0 Input/Output in A/D non-multiplexed mode
and additionally Address 1 Output in A/D multiplexed
mode
GPMC0_AD0
GPMC0_AD1
GPMC0_AD2
GPMC0_AD3
GPMC0_AD4
GPMC0_AD5
IO
IO
IO
IO
IO
IO
M27
M23
M28
M24
N24
N27
GPMC Data 1 Input/Output in A/D non-multiplexed mode
and additionally Address 2 Output in A/D multiplexed
mode
GPMC Data 2 Input/Output in A/D non-multiplexed mode
and additionally Address 3 Output in A/D multiplexed
mode
GPMC Data 3 Input/Output in A/D non-multiplexed mode
and additionally Address 4 Output in A/D multiplexed
mode
GPMC Data 4 Input/Output in A/D non-multiplexed mode
and additionally Address 5 Output in A/D multiplexed
mode
GPMC Data 5 Input/Output in A/D non-multiplexed mode
and additionally Address 6 Output in A/D multiplexed
mode
