ADC0831-N, ADC0832-N, ADC0834-N, ADC0838-N
SNAS531B AUGUST 1999REVISED MARCH 2013
www.ti.com
AC Characteristics
The following specifications apply for VCC = 5V, tr = tf = 20 ns and 25°C unless otherwise specified.
Tested
Design
Limit(3)
Limit
Units
Parameter
Conditions
Typ(1)
Limit(2)
Min
10
kHz
kHz
1/fCLK
%
fCLK, Clock Frequency
Max
400
tC, Conversion Time
Clock Duty Cycle(4)
Not including MUX Addressing Time
8
Min
40
60
Max
%
tSET-UP, CS Falling Edge or Data Input Valid
to CLK Rising Edge
250
90
ns
ns
tHOLD, Data Input Valid after CLK Rising
Edge
CL=100 pF
tpd1, tpd0—CLK Falling Edge to Output Data
Valid(5)
Data MSB First
Data LSB First
650
250
1500
600
ns
ns
CL=10 pF, RL=10k (See TRI-STATE
Test Circuits and Waveforms)
125
250
ns
t1H, t0H,—Rising Edge of CS to Data Output
and SARS Hi–Z
CL=100 pf, RL=2k
500
ns
pF
pF
CIN, Capacitance of Logic Input
5
5
COUT, Capacitance of Logic Outputs
(1) Typicals are at 25°C and represent most likely parametric norm.
(2) Tested limits are ensured to TI's AOQL (Average Outgoing Quality Level).
(3) Ensured but not 100% production tested. These limits are not used to calculate outgoing quality levels.
(4) A 40% to 60% clock duty cycle range insures proper operation at all clock frequencies. In the case that an available clock has a duty
cycle outside of these limits, the minimum, time the clock is high or the minimum time the clock is low must be at least 1 μs. The
maximum time the clock can be high is 60 μs. The clock can be stopped when low so long as the analog input voltage remains stable.
(5) Since data, MSB first, is the output of the comparator used in the successive approximation loop, an additional delay is built in (see
ADC0838-N Functional Block Diagram) to allow for comparator response time.
6
Submit Documentation Feedback
Copyright © 1999–2013, Texas Instruments Incorporated
Product Folder Links: ADC0831-N ADC0832-N ADC0834-N ADC0838-N
