XS2206
Pb
XS2206
Pb Free Plating Product
20Amperes,600Volts Insulated Common Cathode Ultra Fast Recovery Rectifiers
Unit : inch (mm)
ITO-220AB/TO-220F-3L
APPLICATION
.189(4.8)
.406(10.3)
.165(4.2)
.381(9.7)
· Freewheeling, Snubber, Clamp
· Inversion Welder
· PFC
.134(3.4)
.130(3.3)
.114(2.9)
.118(3.0)
· Plating Power Supply
· Ultrasonic Cleaner and Welder
· Converter & Chopper
· UPS
.114(2.9)
.098(2.5)
.071(1.8)
.055(1.4)
.055(1.4)
.039(1.0)
.035(0.9)
.011(0.3)
.032(.8)
MAX
PRODUCT FEATURE
· Ultrafast Recovery Time
.1
(2.55)
.1
(2.55)
· Soft Recovery Characteristics
· Low Recovery Loss
Case
Case
Case
Case
· Low Forward Voltage
Doubler
Tandem Polarity Tandem Polarity
Prefix "XU" Prefix "XUR"
Series
Negative
Common Cathode Common Anode
Prefix "XS" Prefix "XR"
Positive
· High Surge Current Capability
· Low Leakage Current
GENERAL DESCRIPTION
XS2206 using the lastest FRED FAB process(planar passivation chip) with ultrafast and soft recovery characteristic.
Absolute Maximum Ratings
Parameter
Symbol
Test Conditions
Values
Units
Repetitive peak reverse voltage
VRRM
600
V
(total device)
Continuous forward current
IF(AV)
20
Tc =110°C
A
(total device)
Single pulse forward current
IFSM
IFRM
Tj
160
60
Tc =25°C
Maximum repetitive forward current
Operating junction
Square wave, 20kHZ
175
°C
°C
Storage temperatures
Tstg
-55 to +175
Rev.08T
© 1995 Thinki Semiconductor Co., Ltd.
Page 1/2
http://www.thinkisemi.com.tw/
THINKISEMI [ Thinki Semiconductor Co., Ltd. ]
