Packing Options
Data Sheets
TO-202 Type 2 Reel Pack (RP)
Meets all EIA-468-B 1994 Standards
0.02 (0.5)
0.236
(6.0)
1.33
(33.8)
0.63
(16.0)
0.708
(18.0)
0.354
(9.0)
0.1 (2.54)
0.5
(12.7)
0.2 (5.08)
MT1 / Cathode
0.157
(4.0)
Gate
DIA
MT2 / Anode
14.17
(360.0)
Dimensions
are in inches
(and millimeters).
1.97
(50.0)
Direction of Feed
Reel Pack (RP) for TO-252 Embossed Carrier
Meets all EIA-481-2 Standards
0.157
(4.0)
0.059
DIA
(1.5)
Gate
MT1 / Cathode
0.63
(16.0)
0.524
(13.3)
*
0.315
(8.0)
*
Cover tape
MT2 / Anode
12.99
(330.0)
0.512 (13.0) Arbor
Hole Dia.
Dimensions
are in inches
(and millimeters).
0.64
(16.3)
Direction of Feed
