Data Sheets
Packing Options
TO-92 (3-lead) Reel Pack (RP) Radial Leaded
Meets all EIA-468-B 1994 Standards
0.02 (0.5)
0.236
(6.0)
0.098 (2.5) MAX
1.26
(32.0)
1.6
(41.0)
0.708
(18.0)
0.354
(9.0)
0.5
(12.7)
MT1 / Cathode
MT2 / Anode
0.1 (2.54)
14.17(360.0)
0.2 (5.08) Gate
0.157
(4.0)
DIA
Flat up
1.97
(50.0)
Dimensions
are in inches
(and millimeters).
Direction of Feed
TO-92 (3-lead) Ammo Pack (AP) Radial Leaded
Meets all EIA-468-B 1994 Standards
0.02 (0.5)
0.236
(6.0)
0.098 (2.5) MAX
1.27
(32.2)
1.62
(41.2)
0.708
(18.0)
0.354
(9.0)
0.157
(4.0)
MT2 / Anode
0.2 (5.08)
0.5
(12.7)
0.1 (2.54)
MT1 / Cathode
DIA
Gate
Flat down
25 Devices per fold
1.85
(47.0)
12.2
(310.0)
Dimensions
are in inches
(and millimeters).
1.85
(47.0)
13.3
(338.0)
2002 Teccor Electronics
Thyristor Product Catalog
M3 - 3
