Package Dimensions
Single In-line Protector (SIP)
The following illustration shows a balanced three-chip SIP protector:
0.040 0.004
(1.016 0.102)
0.450 +0.010 / -0.002
(11.430 +0.254 -0.051)
0.010
(0.025)
2.250 +0.010 / -0.002
(57.150 +0.254 -0.051)
typ
0.260
(6.604)
max
0.500 (12.70) max
Dimensions are in
inches (millimeters).
0.110 0.010
(2.794 0.254)
0.100 0.010 non-cumulative
(2.540 0.254)
The following illustration shows a longitudinal two-chip SIP protector:
0.040 0.004
(1.016 0.102)
0.450 +0.010 / -0.002
(11.430 +0.254 -0.051)
0.010
(0.025)
2.250 +0.010 / -0.002
(57.150 +0.254 -0.051)
typ
0.260
(6.604)
max
0.500 (12.70) max
Dimensions are in
inches (millimeters).
0.075 0.010
0.020 (0.508) typ
(1.905 0.254)
0.110 0.010
(2.794 0.254)
0.100 0.010 non-cumulative
(2.540 0.254)
