Package Dimensions
Modified TO-220
The Modified TO-220 package is designed to meet mechanical standards as set forth in
JEDEC publication number 95.
A
O
D
G
TEMPERATURE
MEASUREMENT
POINT
F
P
PIN 3
PIN 2
PIN 1
L
M
K
H
N
J
Inches
Millimeters
Dimension
MIN
MAX
0.410
0.375
0.130
0.575
0.035
0.205
0.105
0.085
0.085
0.024
0.188
0.310
MIN
MAX
10.42
9.53
3.30
14.61
0.89
5.21
2.67
2.16
2.16
0.61
4.78
7.87
A
D
F
G
H
J
K
L
M
N
O
P
0.400
0.360
0.110
0.540
0.025
0.195
0.095
0.075
0.070
0.018
0.178
0.290
10.16
9.14
2.80
13.71
0.63
4.95
2.41
1.90
1.78
0.46
4.52
7.37
Notes:
•
All leads are insulated from case. Case is electrically non-conductive. (Rated at 1600 V ac rms for one
minute from leads to case over the operating temperature range)
Mold flash shall not exceed 0.13 mm per side.
•
© 2002 Teccor Electronics
6 - 7
http://www.teccor.com
+1 972-580-7777
®
SIDACtor Data Book and Design Guide
