Description of Part Number
Description of Part Number
The following illustration shows a description of a sample SIDACtor device part number.
P
210
2
A
A
61 RP
PACKING OPTIONS
RP1 = TO-92 reel pack (0.100" lead spacing)
RP2 = TO-92 reel pack (0.200" lead spacing)
AP = Ammo pack
DEVICE TYPE
P = SIDACtor
RP = Reel pack
TP = Tube pack
MEDIAN VOLTAGE RATING
210 = 210 V
LEAD FORM OPTIONS
TO-220 modified type 60, 61, or 62
For U type:
CONSTRUCTION VARIABLE
0 = One chip
1 = Unidirectional part
2 = Two chips
3 = 3 chips
4 = 4 chips
6 = 6 chips
3 = Three chips
I
PP RATING
A = 50 A (10x560 µs)
B = 100 A (10x560 µs)
C = 500 A (2x10 µs)
D = 1000 A (8x20 µs)
E = 3000 A (8x20 µs)
0 = One SIDACtor Chip
1
3
2
2 = Two Matched SIDACtor Chips
PACKAGE TYPE
A = TO–220
C = Three-leaded DO-214
E = TO–92
1
3
M = TO-218
S = DO–214
Patented
U = Six-pin SOIC
Z = SIP
2
3 = Three Matched SIDACtor Chips
http://www.teccor.com
+1 972-580-7777
1 - 8
© 2002 Teccor Electronics
®
SIDACtor Data Book and Design Guide
