Part numbering system
ACT
DEUTSCH System
I
Contact type
P : Male contact
S
: Female contact
Special modifications
A : Without male contact
B : Without female contact 500 cycles contact.
U : Male PCB contact
M : Female PCB contact
3025 : Standard gold
Shell type
Square flange receptacle : 90
* Single hole mounting receptacle : 94
Plug : 96
Shell size
A - B - C - D - E - F
- G - H - J
Consult factory for
availability
ACT
90
*
J
B-35
*
N
*
Arrangements
(See page 5)
Connector type
Finish
Key orientation
* N - A - B - C - D - E
Olive drab cadmium : W
Nickel coating : M
The square flange receptacle is never delivered with panel seal. For ordering panel seals see page 9.
For standard contacts delivered with the connector, see page 10.
MIL-DTL-38999 SYSTEM
I
Contact type
P : Male contact 500 cycles
: Female contact 500 cycles
H : Male, extended life 1500 cycles contact
S
Shell type
Square flange receptacle : 20
** Single hole mounting receptacle : 24
Plug : 26
J
: Female, extended life 1500 cycles
contact
Shell size
A - B - C - D - E - F
- G - H - J
A : Without male contact
B : Without female contact
D38999
20
*
J
19
P
N
Model of designation
Arrangements
(See page 5)
Finish
Key orientation
* N - A - B - C - D - E
Olive drab cadmium : J
Nickel coating : M
* Consult factory for availability
** Consult factory for current QPL listing.
4
