Technical characteristics
ACT
Mechanical
Shell
I
Material
Plating
: Composite
: W - Olive drab cadmium,
M - Nickel coating
Insert
Material
: Thermoplastic and fluorinated silicone elastomer
: fluoronited silicone elastomer
: Copper alloy
Flat gasket and o’ring Material
Contact
Material
Plating
Type
: Gold
: Crimp type or printed circuit pin (consult us)
: Size 22 D: 44 N
Retention
Size 20
Size 16
Size 12
:
:
:
67 N
111 N
111 N
Size 8 : 111 N
Vibrations
: As per MIL-DTL-38999
Physical shocks
Durability
: 300 g, 3 ms in the 3 axes
: 1500 coupling and uncoupling cycles
Climatics
Service temperature
I
: Cadmium plating - 65° C to + 175° C
: Nickel plating
- 65° C to + 200° c
Thermal shocks
Sealing
: As per MIL-DTL-38999
: Leakage ≤ 16 cm3/h on mated connecting under 2,1 bars
Salt spray resistance
: 2000 hours, class W as per MIL-DTL-38999
2000 hours class M, as per MIL-DTL-38999
Electrical
Withstanding voltage
I
at sea level : Service M : 1300 V
Service I : 1800 V
Service II : 2300 V
at 21000 m altitude : Mated connector
Service M : 800 V
Unmated connector
Service M
Service I
: 350 V
: 400 V
: 500 V
Service I : 1000 V
Service II : 1000 V
Service II
Insulation resistance (Ambiant temperature)
Voltage drop
: 5000 MΩ to 25° C and 65 % HR max.
: size 22 : test to
5
Amp. = 73 millivolts max.
Size 20 : test to 7,5 Amp. = 55 millivolts max.
Size 16 : test to 12 Amp. = 49 millivolts max.
Size 12 : test to 23 Amp. = 42 millivolts max.
Size 8 : test to 46
Amp. = 26 millivolts max.
Shielding
: As per MIL-DTL-38999
Contacts current Diameter over
Permitted wire
Sizes
section in mm2
Size
Sealed
Insulation sheath
in mm
version
22
20
16
12
8
5
A
0,76 to 1,37
1,01 to 2,10
1,65 to 2,77
2,46 to 3,61
4,50 to 5,80
0,095 to 0,38
0,21 to 0,60
0,60 to 1,34
1,91 to 3,18
5,30 to 8,98
7,5 A
13 A.
23 A.
46 A.
For more information, see MIL-DTL-38999 series III
3
