13.11 REGISTER 10 – HIGH BYTE OF GYROSCOPE Y-AXIS OIS DATA
Register Name: GYRO_YOUT_OIS_H
Register Type: READ
Register Address: 10 (Decimal); 0A (Hex)
BIT
NAME
FUNCTION
[7:0]
GYRO_YOUT_OIS[15:8] High byte of gyroscope y-axis OIS data.
13.12 REGISTER 11 – LOW BYTE OF GYROSCOPE Y-AXIS OIS DATA
Register Name: GYRO_YOUT_OIS_L
Register Type: READ
Register Address: 11 (Decimal); 0B (Hex)
BIT
NAME
FUNCTION
[7:0]
GYRO_YOUT_OIS[7:0]
Low byte of gyroscope y-axis OIS data.
13.13 REGISTER 12 – HIGH BYTE OF GYROSCOPE Z-AXIS OIS DATA
Register Name: GYRO_ZOUT_OIS_H
Register Type: READ
Register Address: 12 (Decimal); 0C (Hex)
BIT
NAME
FUNCTION
[7:0]
GYRO_ZOUT_OIS[15:8] High byte of gyroscope z-axis OIS data.
13.14 REGISTER 13 – LOW BYTE OF GYROSCOPE Z-AXIS OIS DATA
Register Name: GYRO_ZOUT_OIS_L
Register Type: READ
Register Address: 13 (Decimal); 0D (Hex)
BIT
NAME
FUNCTION
[7:0]
GYRO_ZOUT_OIS[7:0]
Low byte of gyroscope z-axis OIS data.
