General
Specifications
C Series – General Application
No.
16
Item
Performance
Test or Inspection Method
Moisture Resistance
Reflow solder the capacitor on P.C. board (shown in
Appendix 1a or Appendix 1b) before testing.
External
No mechanical damage.
Apply the rated voltage at temperature 40±2ºC and 90
to 95%RH for 500 +24,0h.
appearance
Change from the
value before test
Capacitance
Characteristics
Charge/discharge current shall not exceed 50mA.
Class 1
Class 2
C0G
±7.5% or ±0.75pF,
whichever larger.
Leave the capacitor in ambient conditions for 6 to 24h
(Class 1) or 24±2h (Class 2) before measurement.
X5R
X7R
Y5V
± 25 %
Voltage conditioning (only for Class 2):
± 25 %
Voltage treat the capacitor under testing temperature
and voltage for 1 hour.
± 30 % *(± 40 %)
* Inside ( ) is applied to Y5V 6.3V
product.
Leave the capacitor in ambient conditions for 24±2h
before measurement.
Q
Rated
Q
Capacitance
Use this measurement for initial value.
(Class 1)
C ≥ 30pF
200 min.
C < 30pF
100+10/3×C min.
C : Rated capacitance (pF)
Characteristics
X5R: 200% of initial spec. max.
D.F.
(Class 2)
X7R: 200% of initial spec. max
Y5V: 150% of initial spec. max
Insulation
500MΩor 25MΩ•μF min., whichever
smaller.
Resistance
(As for the capacitors of rated voltage
16, 10 and 6.3V DC, 500 MΩ or
5MΩ•μF min.,)
TDK MLCC US Catalog
Page 69
Version B11
