SMM465
Preliminary Information
DEVELOPMENT HARDWARE & SOFTWARE
The Windows GUI software will generate the data and
send it in I2C serial bus format so that it can be directly
downloaded to the SMM465 via the programming
Dongle and cable. An example of the connection
interface is shown in Figure 15.
The end user can obtain the Summit SMX3200
programming
system
for
device
prototype
development. The SMX3200 system consists of a
programming Dongle, cable and WindowsTM GUI
software. It can be ordered on the website or from a
local representative. The latest revisions of all
software and an application brief describing the
When design prototyping is complete, the software
can generate a HEX data file that should be
transmitted to Summit for approval. Summit will then
assign a unique customer ID to the HEX code and
program production devices before the final electrical
SMX3200
is
available
from
the
website
(www.summitmicro.com).
The SMX3200 programming Dongle/cable interfaces
directly between a PC’s parallel port and the target
application. The device is then configured on-screen
via an intuitive graphical user interface employing
drop-down menus.
test operations.
This will ensure proper device
operation in the end application.
Top view of straight 0.1" x 0.1 closed-side
connector. SMX3200 interface cable connector.
D1
1N4148
Pin 10, Reserved
Pin 8, Reserved
Pin 6, MR#
Pin 9, 5V
Pin 7, 10V
Pin 5, Reserved
Pin 3, GND
Pin 1, GND
Pin 4, SDA
VDD_CAP
Pin 2, SCL
10 9
8
6
4
2
7
5
3
1
SMM465
0.1 F
MR
SDA
SCL
GND
Figure 15 – SMX3200 Programmer I2C serial bus connections to program the SMM465. Note that the MR pin
does not need to be connected to pin 6 for programming purposes.
Summit Microelectronics, Inc
2085 1.1 05/27/04
21
