Package mechanical data
VIPER16
16
Package mechanical data
In order to meet environmental requirements, ST offers these devices in different grades of
®
®
ECOPACK packages, depending on their level of environmental compliance. ECOPACK
specifications, grade definitions and product status are available at: www.st.com.
®
ECOPACK is an ST trademark.
Table 9.
DIP-7 mechanical data
mm
Min
Dim.
Typ
Max
A
A1
A2
b
5,33
0,38
2,92
0,36
1,14
0,20
9,02
7,62
6,10
3,30
0,46
1,52
0,25
9,27
7,87
6,35
2,54
7,62
4,95
0,56
1,78
0,36
10,16
8,26
7,11
b2
c
D
E
E1
e
eA
eB
L
10,92
3,81
3,30
2,508
0,50
2,92
0,40
M (6)(8)
N
0,60
0,60
N1
O (7)(8)
0,548
1- The leads size is comprehensive of the thickness of the leads finishing material.
2- Dimensions do not include mold protrusion, not to exceed 0,25 mm in total (both side).
3- Package outline exclusive of metal burrs dimensions.
4- Datum plane “H” coincident with the bottom of lead, where lead exits body.
5- Ref. POA MOTHER doc. 0037880
6- Creepage distance > 800 V
7- Creepage distance 250 V
8- Creepage distance as shown in the 664-1 CEI / IEC standard.
20/25
Doc ID 15232 Rev 5
