VIPer12ADIP / VIPer12AS
SO-8 TUBE SHIPMENT (no suffix)
B
Base Q.ty
Bulk Q.ty
100
C
A
2000
Tube length (± 0.5)
532
3.2
6
A
B
C (± 0.1)
0.6
All dimensions are in mm.
TAPE AND REEL SHIPMENT (suffix “13TR”)
REEL DIMENSIONS
Base Q.ty
Bulk Q.ty
A (max)
B (min)
C (± 0.2)
F
2500
2500
330
1.5
13
20.2
12.4
60
G (+ 2 / -0)
N (min)
T (max)
18.4
All dimensions are in mm.
TAPE DIMENSIONS
According to Electronic Industries Association
(EIA) Standard 481 rev. A, Feb 1986
Tape width
W
P0 (± 0.1)
P
12
4
Tape Hole Spacing
Component Spacing
Hole Diameter
8
D (± 0.1/-0) 1.5
Hole Diameter
D1 (min)
F (± 0.05)
K (max)
1.5
5.5
4.5
2
Hole Position
Compartment Depth
Hole Spacing
P1 (± 0.1)
End
All dimensions are in mm.
Start
Top
No components
500mm min
Components
No components
cover
tape
Empty components pockets
saled with cover tape.
500mm min
User direction of feed
13/15
