TDA7719
Pin connections and pin descriptions
2
Pin connections and pin descriptions
2.1
Pin connections
Figure 2.
Pin connections (top view)
2.2
Pin description
Table 2.
Pin description
Pin name
QD1L / SE1L / MD3+
No.
Description
I/O
1
2
3
4
5
6
7
8
9
QD1 left input or SE1 left or MD3 positive input
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
QD1R / SE1R / MD3- QD1 right input or SE1 right input or MD3 negative input
QD1G / SE2L
QD2G / SE2R
QD2L / SE3L
QD2R / SE3R
QD3L
QD1 common input or SE2 left input
QD2 common input or SE2 right input
QD2 left input or SE3 left input
QD2 right input or SE3 right input
QD3 left input
QD3G
QD3 common input
QD3R
QD3 right input
7/45
