软件规格
TDA75610LV
Bit
表9. DB1 (续)
指令代码
Channel LF (CH1)
D1
D0
No short to Vcc (D1 = 0)
Short to Vcc (D1 = 1)
-
-
Channel LF (CH1)
No short to GND (D1 = 0)
Short to GND (D1 = 1)
表10. DB2
指令代码
Bit
Offset detection not activated (D7 = 0)
Offset detection activated (D7 = 1)
D7
D6
-
X
-
Channel LR (CH2)
Channel LR (CH2)
Current detection IB2 (D7) = 0
Current detection IB2 (D7) = 1
D5
Output peak current < 250 mA - Open load (D5 = 1) Output peak current < 125 mA - Open load (D5 = 1)
Output peak current > 500 mA - Normal load (D5 = 0) Output peak current > 250 mA - Normal load (D5 = 0)
Channel LR (CH2)
D4
D3
Turn-on diagnostic (D4 = 0)
-
-
Permanent diagnostic (D4 = 1)
Channel LR (CH2)
Normal load (D3 = 0)
Short load (D3 = 1)
Channel LR (CH2)
Turn-on diag.: No open load (D2 = 0)
Open load detection (D2 = 1)
Permanent diag.: No output offset (D2 = 0)
Output offset detection (D2 = 1)
D2
-
Channel LR (CH2)
D1
D0
No short to Vcc (D1 = 0)
Short to Vcc (D1 = 1)
-
-
Channel LR (CH2)
No short to GND (D1 = 0)
Short to GND (D1 = 1)
深圳市云嘉伟业科技有限公司 电话 0755-28747461 手机 13538050392 公司网址：http://www.yunjiaweiye.com
DocID024173 Rev 7
33/42
