STV0681
Introduction
1.2.2 User features on camera
● Self-timer mode allows a picture to be captured after several seconds.
● Twin 7 segment LCD panel supported - showing number of pictures left, and modes.
● Picture counter helps the user to know how much memory is left.
● Un-tethered ‘Continuous’ mode allows capture of image sequences for storage in memory and
subsequent download to PC.
● Piezo buzzer indicates a number of useful events to the user, e.g. whether enough light is present for
picture capture, etc.
● LED indicator .
● “Clear all” function clears camera.
● “Low Resolution” mode increases number of images which can be captured by reducing image
resolution.
● Audio Record function (if audio record hardware detected) allows sounds to be recorded.
● Audio Playback function (if audio playback hardware fitted) allows sounds which have been recorded
to be played back.
● “Delete last” function allows user to delete audio memos, pictures or continuous clips, deletion must
be carried out “most reset first”.
● Camera can be configured by the user to play custom sounds at certain functions, using a PC
application.
● “Go to sleep” function, whereby the camera can be put into standby mode while untethered.
1.2.3 User features on PC software
PC software allows a number of features such as fast download of thumbnail images for picture
selection, and automatic detection and correction of sensor defects. The driver compatibility
includes:
● TWAIN driver to suit all TWAIN compatible imaging applications
● Video for Microsoft Windows PC driver for tethered video mode (through USB), available at all
resolutions, with fastest framerates at QCIF resolution
● AVI video file creation from image sequences captured in ‘continuous’ mode
● Quicktime Video driver and Adobe Photoshop stills plug-in for Mac
Custom OEM PC software can be developed by using the SDK (for SDK availability, contact ST), to
upload thumbnails/still images or ‘continuous’ images, e.g. for AVI file creation.
The SDK (version 2.90 or later) allows:
● the OEM to write a custom application and upload sound memos based on the example LCDC demo
software.
● the OEM to write a custom application and download custom sounds to the camera based on the
example CustomSound software.
1.2.4 Power management features and USB compliance
● Retention of pictures, recorded sounds and downloaded custom sounds with extremely low power
operation. The camera seems to be “switched off”.
● Auto power-off after 30 seconds of non usage.
● Operates from 4.5-6V battery, although system voltage is 5V or 3.3V, dependant on sensor.
● Low battery detection.
