Software support
STV0681
6.2
Software installation
The following software support is only available to OEMs. Access to the latest installation files is
possible through a password-protected web page, contact ST for details. The installation files are for
the following:
● Drivers (always check the Web site for latest driver version).
● EVK software, i.e. LCDCdemo.exe and AVIcreator.exe, G2Video.exe, and CTItest2.exe
● SDK installation: source code for sample applications, and documentation
6.2.1 Driver support available
Table 5: Driver choices
RS232
USB
Interface type:
Microsoft Windows
:
Microsoft Windows
Win98 and Win2k only,
Windows millenium
Windows XP
:
Win9x, WinNT4, Win2k,
Windows Millennium
Windows XP
PC Operating system
N/A
8.6, 9.0, 9.1, 9.2
Mac OS
6.2.2 EVK software
Note: The following is also supplied with evaluation kits/demonstration units, but all the following software
is only for demonstration purposes and should NOT be supplied as an end-user product. However,
application-level source code (i.e. not driver/colour processing source) for LCDCdemo.exe, AVI
creator, and CTItest.exe is available as part of the SDK, which allows similar applications to be built
by the software developer:
1
2
3
Simple demonstration software LCDCdemo.exe for uploading thumbnails and images.
AVIcreator.exe software for uploading continuous images for creating ‘movie’ clips.
G2Video.exe is a VfW application which shows streaming video while tethered to USB and
allows creation of.AVI video clips.
4
CTItest.exe is only for debugging purposes, for software developers using the SDK
6.2.3 Software Development Kit (SDK) and source code
A software development kit allows the OEM to develop a custom application which calls the same
range of drivers as listed in Section 6.2.1, hence allowing the OEM application to perform picture
download, thumbnail display, and colour processing using the ST colour process. Inclusion of
source code for the applications listed in Section 6.2.2 allows the software developer to use these
as the basis for their own application.
TM
The SDK is supplied by ST as a 32-bit DLL format, running on Microsoft Windows 98/Win2K , and
accessed through a documented software interface. Development requires Microsoft Visual Studio
Version 6 or later. This provides the basis for developing a custom software application for stills.
Note: Source code for PC Drivers, Defect Correction and Colour Processing algorithms are not available.
30/44
ADCS 7283313C
