STM32F105xx, STM32F107xx
Electrical characteristics
Table 17. Typical current consumption in Run mode, code with data processing
running from Flash
Typ(1)
Symbol Parameter
Conditions
fHCLK
Unit
Allperipherals Allperipherals
enabled(2)
disabled
72 MHz
48 MHz
36 MHz
24 MHz
16 MHz
8 MHz
47.3
32
28.3
19.6
15.4
10.6
7.4
24.6
16.8
11.8
5.9
External clock(3)
3.7
mA
4 MHz
3.7
2.9
2 MHz
2.5
2
1 MHz
1.8
1.53
1.3
Supply
current in
Run mode
500 kHz
125 kHz
36 MHz
24 MHz
16 MHz
8 MHz
1.5
IDD
1.3
1.2
23.9
16.1
11.1
5.6
14.8
9.7
6.7
Running on high
speed internal RC
(HSI), AHB
3.8
4 MHz
3.1
2.1
mA
prescaler used to
reduce the
frequency
2 MHz
1.8
1.3
1 MHz
1.16
0.8
0.9
500 kHz
125 kHz
0.67
0.5
0.6
1. Typical values are measures at TA = 25 °C, VDD = 3.3 V.
2. Add an additional power consumption of 0.8 mA per ADC for the analog part. In applications, this
consumption occurs only while the ADC is on (ADON bit is set in the ADC_CR2 register).
3. External clock is 8 MHz and PLL is on when fHCLK > 8 MHz.
