STM32F405xx, STM32F407xx
Memory mapping
Table 10. STM32F40x register boundary addresses (continued)
Bus
Boundary address
Peripheral
0x4004 0000 - 0x4007 FFFF
0x4002 9400 - 0x4003 FFFF
0x4002 9000 - 0x4002 93FF
0x4002 8C00 - 0x4002 8FFF
0x4002 8800 - 0x4002 8BFF
0x4002 8400 - 0x4002 87FF
0x4002 8000 - 0x4002 83FF
0x4002 6800 - 0x4002 7FFF
0x4002 6400 - 0x4002 67FF
0x4002 6000 - 0x4002 63FF
0x4002 5000 - 0x4002 5FFF
0x4002 4000 - 0x4002 4FFF
0x4002 3C00 - 0x4002 3FFF
0x4002 3800 - 0x4002 3BFF
0x4002 3400 - 0x4002 37FF
0x4002 3000 - 0x4002 33FF
0x4002 2400 - 0x4002 2FFF
0x4002 2000 - 0x4002 23FF
0x4002 1C00 - 0x4002 1FFF
0x4002 1800 - 0x4002 1BFF
0x4002 1400 - 0x4002 17FF
0x4002 1000 - 0x4002 13FF
0x4002 0C00 - 0x4002 0FFF
0x4002 0800 - 0x4002 0BFF
0x4002 0400 - 0x4002 07FF
0x4002 0000 - 0x4002 03FF
0x4001 5800- 0x4001 FFFF
USB OTG HS
Reserved
ETHERNET MAC
Reserved
DMA2
DMA1
Reserved
BKPSRAM
Flash interface register
RCC
AHB1
Reserved
CRC
Reserved
GPIOI
GPIOH
GPIOG
GPIOF
GPIOE
GPIOD
GPIOC
GPIOB
GPIOA
Reserved
